D400 Framed Drainage Grating 450 × 750 (HT-059)
HT-059
Framed Drainage Grating in load class D400, specification 450X750.
Load Class
Specification
Casting Weight
Reference
HT-059
Share the quantity and delivery destination with your inquiry.
Product Specifications
The framed drainage grating HT-059 has listed size 450 x 750, load class D400 and a rubber seal. Refer to the catalog table below and quote HT-059 when requesting drawings or product details.
Product specifications
| Load class | D400 |
|---|---|
| Specification | 450X750 |
| Cover size | 450X750 |
| Frame size | 570X870 |
| Height | 85 |
| Seating depth | 45 |
| Clear opening | 370X650 |
| Casting weight, frame / cover (kg) | 105KG |
| Hinge / retaining device | Yes |
| Rubber seal | Yes |
| Catalog reference | HT-059 |
Product Details
Product Configuration
Review the cover, frame or grating configuration shown in the product images.
Installation Details
Confirm openings, dimensions and any fixing features required by the project.
Specification Review
Confirm installation conditions and specification requirements with our team before ordering.
